·Description：
1.With digital scale display,it can manually lift the lifting pressing frame.
2.Widely used for cutting and grooving of density boards, composite boards and non-wood fillers.
·Specification：
| model | KMBS3100-X |
| 型号 | |
| place of origin | Guangdong,China |
| 产地 | 中国广东 |
| width of workpiece | max:3100mm |
| 工件宽度 | |
| thickness of workpiece | max:60, min:5mm |
| 工件厚度 | |
| length of workpiece | min 600mm |
| 工件长度 | |
| spindle dia. | 25.4mm |
| 主轴直径 | |
| spindle rpm | 2600 r/min |
| 主轴转速 | |
| saw blade dia. | 320mm |
| 锯片直径 | |
| power of spindle motor | 3×5pcs |
| 主轴电机功率 | |
| power of feeding motor | 1.5kW |
| 送料电机功率 | |
| total power | 16.5kW |
| 总功率 | |
| feeding speed | 0-12m/min |
| 送料速度 | |
| qty of feeding roller | 4sets/8pcs |
| 送料棍组数/条数 | |
| dust collector outer dia. | 50mmx5pcs, 150mmx5pcs |
| 排屑管外径 | |
| overall dimension | 3200x1500x1450 mm |
| 外形尺寸 | |
| weight | 3000kg |
| 重量 | |
| power source | 380V, 50Hz,3P |
| 电源 | |
| CE certificate | √ |
| CE认证 |
